17000DWT散货船主要参数
main parameter for 17000 DWT bulk carrier |
用途：以装散货为主兼装干杂货。可装运散煤、钢材、谷物、矿砂，袋装粮食、袋装水泥等不易燃货物。
Usage:it will be used for carrying bulk cargo and dry grocer,and also it could carry nonflammable cargo,such as bulk coal,steel products,grist,ore,grain in bags and cement in bags,etc.
|
总长
LOA |
150.9M |
主发电机组型号
model of diesel generator set |
CCFJ300J-WD×3sets |
主发电机组柴油机型号、功率
model&rated power of diesel engine |
X6170ZC-013/330KW |
主发电机组发电机型号、功率
model&rated power of generator |
TFHX-300/300KW |
设计水线长
LWL |
145.3M |
应急发电机组型号
model of emergency diesel generator set |
64GFC22a×1set |
应急发电机组柴油机型号、功率
model&rated power of diesel engine |
6135D-3/83.8KW |
应急发电机组发电机型号、功率
model&rated power of generator |
TFHX-64/64KW |
两柱间长
LPP |
142.3M |
机舱控制方式
E/R control mode |
机舱监控
E/R monitor and control |
型宽
breadth moulded |
21.0M |
螺旋桨（单桨）propeller |
锰铝青铜五叶MAU型定螺距，右旋转向
Mn Al Bronze,,MAU(5leaves),fixed pitch, right hand |
型深
depth moulded |
11.4M |
救生艇型式
model of life boat |
自由降落式救生艇×1艘×25人
free fall lifeboat×1set×25p
刚性单点救助艇×1艘×6人
rescue boat×1set×6p |
满载/设计吃水
full load&design draft |
8.30M |
| 总吨位GT |
10157 |
救生筏 life raft |
1只×6人（抛投式气胀式）
1set×6p(inflatable type)
2只×12人（气胀式）
2sets×12p(inflatable type) |
| 净吨位NT |
5687 |
载重量吨
deadweight |
~17000t |
克令吊 crane |
24m×20T×2台 |
货舱舱容(4舱)
capacity( four cargo holds) |
total: ：21789.2m3
No.1：5223.3m3
No.2：5551.7m3
No.3：5551.7m3
No.4：5462.5m3 |
杂物吊 miscellany crane |
2台 two sets |
| 锚机 anchor windlass |
2台 φ52单侧式液压组合式锚机
two sets,φ52 |
续航力
endurance |
3600nmile |
锚 anchor |
3只×4590kg |
| 航速speed |
12.1Kn |
锚链 anchor chain |
Φ52有档电焊锚链2根 |
| 航 区 navigation area |
国内航行
domestic |
冰区加强 ice reinforcement |
D级 |
| 船员人数crew |
21people |
舱盖形式
type of hatch cover |
液压顶升式风雨密钢质
hydraulic and weather tightness |
主机型号/功率/转速
M/E model & rated power &speed |
8N330-EN/3310KW/620r/min |
上层建筑数
superstructure number |
5层、层高2.65m~2.9m
five floors,each floor height:2.65 m~ 2.9 m |
| 主机生产厂家/技术国家maker/technology country |
青岛淄柴博洋柴油机股份有限公司Qingdao Zichai Boyang Diesd EngineCo.,Ltd
日本制造made in Japan |
机舱内双层底高度
height of double bottom in E/R |
1350mm |
货舱双层底高度
double bottom height of cargo hold |
1300mm |
主机燃油消耗率/滑油消耗率
fuel and lub oil consumption ratio |
≤190g/kw.h+3%
≤1.1g/kw.h |
货舱舷侧结构
broadside structure
of cargo hold |
单壳结构 single skin |
主机燃油粒度
ME fuel granularity |
1500S（180cst/50℃） |
船级社 class |
RS |
| 锅炉 boiler |
燃油废气组合锅炉
fuel&exhaust composite boiler |
建造单位 builder |
浙江东红船业有限公司
Zhejiang Donghong Shipbuilding Co.,Ltd |
齿轮箱型号/减速
model&reduction ratio of gear box |
GWC66.75/4.969:1（高弹联轴） |
设计单位
Design institute |
浙江现代船舶设计研究有限公司
zhejiang modern ship design research co.,ltd |
