13000DW杂货船主要参数                       main parameter for 13000 DWT general cargo ship
用途：本船适于装载：杂货、货舱里装重货。 Isage:The vessel is suitable for the carriage of general cargo , heavy cargo in cargo holds .
总长 LOA	120.50M	主发电机组型号 model of diesel generator set	CCFJ 250JCM×3sets
		主发电机组柴油机型号、功率 model & rated power of diesel engine	NTA855G2M /283KW
		主发电机组发电机型号、功率 model & rated power of generator	MP-H-250-6PM/250kW
垂线间长 LPP	113.80M	应急发电机组型号 model  of  emergency  diesel generator set	CCFJ120YDM×1set
		应急发电机组柴油机型号、功率 model & rated power of diesel engine	6CTA8.3-GM155/ 155KW
		应急发电机组发电机型号、功率 model & rated power of generator	MP-H-120-4PM/120KW
型宽 breadth moulded	22.00M	锅炉 boiler	燃油废气组合锅炉 fuel&exhaust composite boiler
型深 depth moulded	11.00M	机舱控制方式 E/R control mode	机舱集控 E/R centralized control
设计吃水 design draft	8.00M	螺旋桨（单桨）propeller	锰青铜,固定螺距,右旋,φ4.9m Mn Bronze,fixed pitch, right hand,φ4.9m
结构吃水 scantling draft	8.20M
满载吃水 draf(full load)	8.00M	救生艇型式 model of life boat	自由抛入式救生艇×1套×22人 救助艇×1套×6人 free fall life boat×1set×22p rescue boat ×1set×6p
总吨位GT	8604
净吨位NT	5499	救生筏 life raft	2套×25人          1套×6人      2sets×25p         1set×6p
载重量吨 deadweight	≈13000T	克令吊 crane	24m×20T×2台
货舱舱容(4舱) capacity( four cargo holds)	total:  18788.20m3 NO.1:4788.0m3 NO.2:4818.6m3 NO.3:4818.6m3 NO.4:4362.9m3	锚机 anchor windlass	2套     two sets
		锚 anchor	3只×3443kg
续航力 endurance	7000nmile	锚链 anchor chain	Φ52AM3 有档锚链
航速 speed	~12Kn	冰区加强 ice reinforcement	Ice Class 1D
航 区 navigation area	无限航区 unrestricted	舱盖形式 type of hatch cover	液压、风雨密 hydraulic and weather tightness
船员人数 crew	21 people	上层建筑数 superstructure number	6层、层高    2.8 m~ 3  m six floors,each floor height:2.8 m~ 3  m
主机型号/功率/转速 M/E model & rated power &speed	YANMAR8N330-EN /3310KW /620 r/min	机舱内双层底高度 height of double bottom in E/R	1450mm
主机生产厂家/技术国家 maker/technology country	青岛淄柴博洋柴油机股份有限公司/日本制造 Qingdao Zichai Boyang Diesd EngineCo.,Ltd /made in Japan	货舱双层底高度 double bottom height of cargo hold	1250mm
		货舱舷侧结构 broadside structure of cargo hold	单壳结构  single skin
主机燃油消耗率/滑油消耗率 fuel and lub oil consumption ratio	0.628t/h 3.641kg/h	船级社 class	BV
主机燃油粒度 ME fuel granularity	1500S（180cst/50℃）	建造单位 builder	浙江东红船业有限公司 Zhejiang Donghong Shipbuilding Co.,Ltd
齿轮箱型号/减速 model&reduction ratio  of gear box	GWC70.76/ 5.04:1	设计单位   Design institute	上海伍克能船舶设计(上海)有限公司Conan Wu & Associates
